ALR-W60

ALR-W60-2L2T

Name: ALR-W60
Brand: Waaree Autonova

Compact precision for light payloads.

The ALR-W60-2L2T is a compact latent lifting AMR designed for precise pallet transport in industrial environments. With reliable SLAM navigation, precise stopping accuracy, and a robust safety system, it delivers stable and efficient automation for warehouses and production facilities.

Request a demo Download spec sheet

Payload: 60 kg
Max Speed: 3 m/s
Runtime: 8 h
Accuracy: ±10 mm

Scale · 1:10710 × 510 × 305 mm

Waaree Autonova · Industrial automation platformEngineered & manufactured by Waaree Autonova in IndiaEN 1525 safety compliantEN 12895:2015+A1:2019EN IEC 61000-6-2:2019EN IEC 61000-6-4:2019SAP · Oracle · Microsoft connectorsERP · WMS · MES integrations99.9% fleet uptime SLADeployments across 12+ industries24 × 7 operations supportIndustry 4.0 reference architectureWaaree Autonova · Industrial automation platformEngineered & manufactured by Waaree Autonova in IndiaEN 1525 safety compliantEN 12895:2015+A1:2019EN IEC 61000-6-2:2019EN IEC 61000-6-4:2019SAP · Oracle · Microsoft connectorsERP · WMS · MES integrations99.9% fleet uptime SLADeployments across 12+ industries24 × 7 operations supportIndustry 4.0 reference architecture

Overview

Built for the floor, from the floor up.

Highlights

60 kg rated load capacity
Compact precision design for light payloads
Forward and backward movement with in-place rotation
Compact dimensions: 710 × 510 × 305 mm
Maximum speed up to 3.0 m/s

Specifications

Basic Parameters

Model: ALR-W60-2L2T
Type: Latent Lifting AMR
Rated Load: 60 kg
Product Dimensions (L×W×H): 710 × 510 × 305 mm
Rotation Diameter: 778 mm
Lifting Distance: 60 mm
Ground Clearance: 20 mm
Lifting Pallet Dimensions: 620 × 380 mm
Lifting Method: Motor-driven
Machine Weight: 170 kg
LCD Display: Supported
Touch Screen: Supported
Drive Method: Two-wheel differential drive
Navigation: QR code, texture, laser SLAM
Communication Mode: Wi-Fi

Mobility & Performance

Maximum Operating Speed: 3.0 m/s
Max Acceleration (No Load): 1.5 m/s²
Stopping Position Accuracy (No Load): ±10 mm
Stopping Angle Accuracy (No Load): ±1°
Climbing Ability: 3° / 5%
Obstacle Crossing Height: 10 mm

Safety & Obstacle Avoidance

Obstacle Avoidance Method: Laser + TOF
Collision Bar Detection: Front & Rear
Emergency Stop Button: Front & Rear
Acoustic & Optical Alarm: Supported

Battery & Charging

Rated Operating Time: 8.0 hours
Charging Time: 1.5 hours
Charging Mode: Manual / Automatic, manual battery replacement
Charge–Discharge Cycle Life: 1500 cycles

Operating Environment

Operating Temperature: 0°C to 40°C
Charging Temperature: 0°C to 40°C
Operating Humidity: 5%–90% RH (non-condensing)
